Cutting-Edge Technology is Key to Supplement Screening

Kerri LeVanseler

September 10, 2012

6 Min Read
Cutting-Edge Technology is Key to Supplement Screening

Doping in sports has secured several headlines in the last few years with major publications such as Sports Illustrated and The Wall Street Journal questioning the integrity of dietary supplements and other sports nutrition products and their potential for causing harm to users. International athletes must be vigilant when consuming over-the-counter (OTC) products to avoid consumption of compounds that are prohibited by professional sports organizations. More recently, there have been concerns about excessive amounts of stimulants in consumer products, including dietary supplements and food/beverage items. Warnings have spread to school-age athletes. Parents and coaches are being warned about the dangers that lurk in the sports nutrition products young athletes consume in an attempt to improve their athletic performance.

 FDA has issued warnings about more than 70 weight-loss supplements that include potentially dangerous ingredients. Steroids, steroid-like ingredients, stimulants and prescription drugs found in contaminated products have been reported to cause serious side effects including liver damage, stroke and kidney failure.

With so much at stake, it is clear why the nutraceutical industry has responded with a renewed fervor for demonstrating the quality and safety of dietary supplements. Third-party testing and certification of dietary supplements and sports nutrition products has remained the champion for manufacturers that seek a reliable method for verifying the integrity and safety of their products. But as new designer drugs and steroid-mimicking compounds evolve, so must the technology used to test for these substances. Much of the success of screening for banned athletic substances lies on staying one step ahead of the culprits.

This means laboratories are faced with the challenge of relentlessly developing new testing methodologies and utilizing the most cutting-edge equipment around. Fortunately, the technology used to screen supplements and sports nutrition products has advanced for even the most complex of banned substances.

The Issues and Methods

The World Anti-Doping Agency's (WADA) list of prohibited substances is not short. It covers a veritable cornucopia of stimulants, narcotics, diuretics, beta-2 agonists and, of course, steroids. But even with so many of these performance-boosting compounds identified for testing, more are being developed. There have been several cases of dietary supplements that are laced with untested or undetectable banned substances. Clever chemistry can be deceiving by: 1) creating new compounds that act the same as banned substances, hence mimicking the same performance-boosting effect, and 2) masking banned substances by making them look like the other compounds in the product or influencing the expected natural ratios between chemicals in the body.

So how do testing and certification organizations test for these banned substances? Certified dietary supplement products go through several complex and very rigorous testing procedures before they make it to store shelves. But the main method for identifying and measuring potential banned substances in a supplement is by using liquid chromatography and gas chromatography, coupled with mass spectrometry detection (LCMS and GCMS).



The Technology

Using mass spectrometry (MS) to analyze for substances in a supplement allows scientists to not only identify the compounds used, but also to verify their quantity. The chromatography system allows for the separation of the various components present in the sample. Then, the mass spectrometry detector ionizes and fragments the compounds. Once formed, these ions are accelerated or deflected by electric and magnetic fields. Differences in the mass-to-charge ratio of the ions produced from a compound generate a total ion pattern that can be compared to reference compounds to confirm identity. In order to improve the sensitivity of the MS detector, specific masses are monitored that are the most abundant for the compounds of interest, allowing for the detection of potential contaminants among the multitude of intentional ingredients in the product formulations. Using triple-quadrupole or tandem mass spectrometers (LCMSMS or GCMSMS systems) allow for further selectivity by monitoring specific precursor ions as they transition to product ions. A single compound may have several transitions, and how unique the transitions are to that chemical will allow for the measurement of that compound in the presence of many other components. The frequency or the intensity of the signal measured for the transition is proportional to the concentration present in the sample. Therefore, a reference standard can be prepared at different concentrations to create a calibration curve. The quantitative amount of a substance in a sample can then be determined in comparison to the curve. But what if the analyst is looking for an unknown chemical?

Meet the LTQ Orbitrap. This type of LCMS system offers an edge over the triple-quadupole LCMSMS systems for the detection of unknown chemicals due to its ability to measure the exact mass for the fragment ions. Typical LCMS systems have whole unit mass resolution, which means it can measure the mass-to-charge of the ion to within +/- 1 dalton (Da). The Orbitrap can discriminate between small mass differences, out to 0.004 dalton(Da) with less than a two parts-per-million (ppm) mass error or ±0.0008 Da. This is crucial because the difference between the mass of an acceptable compound and a banned substance sometimes comes down to a hundredth of the molecule's mass.

The ability to identify modifications or structural changes of molecules is increasingly important as new designer drugs, steroids and steroid-like substances emerge and reference chemicals may not always be available. Knowing the exact mass of the ions is key to determining which elements may be present in that ion and in what combination. In this way, the Orbitrap data can be used to elucidate chemical structure information for unknown chemical adulterants. The Orbitrap instrument is most effective when the unknown chemicals are present in the samples at least at low ppm levels. This allows for adequate intensities of the ion peaks, which results in the highest level of accuracy and confidence in the exact mass determinations and conclusions drawn from the data. Since banned compounds may be present in minor concentrations, down to part per billion (ppb) levels, the instrument system used needs to be well suited for the analysis goals. By combining Orbitrap technology for unknown determinations with triple-quadrupole (MSMS) systems for trace level detection of specific known banned substances, the best of both worlds is achieved to ensure the products evaluated are free of unwanted contaminants.

The use of new technologies and laboratory methodologies to test supplements ushers in a new era of contamination and banned substance detection. Instruments like the LTQ Orbitrap mass spectrometer allows organizations to not only to identify and measure compounds and banned substances in dietary supplements; they can also use this technology to identify new banned compounds as they emerge and can help bring awareness of them to the arena of testing and enforcement.

Kerri LeVanseler, Ph.D., is the technical manager of NSF Internationals Chemistry Laboratory  and has over 25 years of experience. She is an expert in a wide range of laboratory techniques and analysis of analytes in various sample types. She also serves on the Joint Committee for the American National Standard for Dietary Supplements (NSF/ANSI 173).

Learn more about testing athletic supplment testing in the SupplySide West education session "Sports Nutrition" on Wed., Nov. 7, from 3 to 3:50 p.m. with speakers Edward Wyszumiala, general manager, dietary supplements programs, NSF International, and Amy Eichner, Ph.D., special advisor on drugs and supplements, U.S. Anti-Doping Agency.
